Axiom AX12LF 12 x 3.5-Inch High-Power Passive Portable Line Array Element Speaker

Axiom AX12LF 12 x 3.5-Inch High-Power Passive Portable Line Array Element Speaker
The AX12LF Line Array is a passive system equipped with twelve 3.5” long-excursion neodymium transducers with waterproof cones, designed to provide low-frequency extension for AX12C and AX6C multiple systems. Wherever a subwoofer is not needed, such as in speech applications or corporate events, the AX12LF provides a one octave low frequency extension to the AX12C and AX6C. The same lightweight aluminum frame box and the common suspension systems allow perfect integration with AX12C and AX6C elements.
The AX12LF line array module can be combined in different configurations with the AX12C (or AX6C – basically two AX6C correspond to one AX12C). Possible configurations range from a simple two-unit column with one AX12C plus one AX12LF suspended or installed on the ground, four-unit columns with one AX12LF at the base or one at the base and one at the top, and very large suspended systems with four AX12C and two AX12LF at the back (end fire configuration). The AX12LF can be powered using QC Series Class D processed amplifiers. Different presets for different combinations are available for the built-in CORE DSP, which can be also remotely controlled using PRONET AX software.
Key Features
High Power passive portable Line Array element
12 x 3.5” long-excursion neodymium transducers with waterproof cones
320W continuous power – 640W program power
90 – 200 Hz low-frequency extension for AX12C and AX6C systems
Acoustic transmission line back loading design
Fast, easy-to-use integrated suspension system
Aluminum frame structure
Designed for mobile and installed applications
Black or white finish
Technical Specifications
SYSTEM System’s Acoustic Principle Line Array Element Short Transmission Line Back Loading Acoustic Diffractor Frequency Response (-6dB) 90 Hz – 200 Hz (Processed) Nominal Impedance 8 Ohm Horizontal Coverage Angle 360° Sensitivity (2.83V) 99 dB SPL @ 1m* Maximum (peak) SPL 124 dB SPL @ 1m* TRANSDUCERS Type 12 x 3.5” (88mm) Neodymium magnet woofers, 1” (25mm) VC Cone Waterproof Cone Voice Coil Type Ventilated voice coil INPUT CONNECTIONS Connector Type Neutrik Speakon NL4 x 2 (1+/1- signal IN & LINK; 2+/2- thru) POWER HANDLING Continuous AES Pink Noise Power 320 W Program Power 640 W ENCLOSURE & CONSTRUCTION Width 107 mm Height 1166 mm (without flying system) 1212 mm (with flying system) Depth 193 mm Enclosure Material Aluminum Paint High resistance, water-based paint Flying system Aluminum Fast Link structure with dedicated pins Net Weight 13.2 kg (without flying system) 15.3 kg (with flying system)
